guide wire. Although techniques using arteriovenous loops have

been described previously,

19,22

they never gained widespread

acceptance, either because the wire was snared inside the left

ventricle,

or because the balloon was advanced through the

arterial end of the loop.

With the current catheters, guide wires

and snares available, our technique is definitely much more

straightforward than the originally proposed variants.

This technique may be considered a good option in resource-

limited settings where the Inoue balloon is not always an available

option. Compared with the Inoue balloon, the total cost of the

Nucleus balloon and its associated hardware is significantly less.

Besides, the Nucleus balloon is easier to clean and resterilise as it

has a single layer, compared to cleaning the Inoue balloon. It can

be reused multiple times, offering a significant cost advantage

in resource-limited settings such as ours. This technique may

also be easier for use in children by paediatric interventionists

who may not be familiar with the Inoue balloon technique but

frequently use arteriovenous loops for other interventions.

One of our patients developed a tear in the anterior mitral

valve leaflet and underwent valve replacement surgery. This

complication may not be associated specifically with the

described technique and could potentially occur with the Inoue

balloon and other techniques. In fact, when inspected by the

surgeon, the valve appeared too dysplastic to attempt repair.

However, our technique carries a potential complication of

inflating the balloon partially in the left ventricular outflow tract,

thus avulsing the sub-valvar mitral apparatus. Great care has to

be taken to not fully inflate the balloon if it seems to engage

partially in the outflow tract during gentle initial inflation.

Although our patient population was small, the outcomes

achieved in terms of increase in mitral valve area and reduction

of mean transmitral diastolic gradient were comparable to

those obtained with the Inoue balloon and other techniques.

21,23

Estimated pulmonary artery pressure also dropped significantly.

These outcomes were maintained on follow up at close to two

years. Except for one patient who had an anterior leaflet tear

leading to severe mitral regurgitation, the degree of mitral

regurgitation was mild or less in all cases at the last follow up.

A limitation is that the number of patients in our study was

relatively small. Furthermore, we did not compare our technique

head to head with other techniques; it was based rather on a

literature review.

Conclusion

The Inoue balloon is not usually available in our centre as we get

most of our consumables on donation. Our modified Nucleus

balloon technique for mitral valve dilation in patients with mitral

stenosis is effective and safe. The technique differs from other

over-the-wire balloon techniques described in the past in that it

avoids placing a stiff wire in the left ventricle, avoiding the risk

of ventricular arrhythmia. It also offers better balloon stability

and control owing to the arteriovenous loop. This technique can

potentially be used with any other balloon available and may

be easier for use by paediatric interventionists who might not

be familiar with the Inoue balloon technique. TEE guidance is

very useful to avoid the potential risk of inflating the balloon

in the left ventricular outflow tract or through the sub-valvar

apparatus. The Nucleus balloon can also be resterilised and used

multiple times.

References

Thakur JS, Negi PC, Ahluwalia SK, Vaidya NK. Epidemiological

survey of rheumatic heart disease among school children in the Shimla

Hills of northern India: prevalence and risk factors.

J Epidemiol

Commun Health

1996;

: 62–67.

Padamavati S. Rheumatic fever and rheumatic heart disease in develop-

ing countries.

Bull World Health Org

1978;

: 543–550.

Rick AR, Gregory JE. Experimental evidence that lesions with basic

characteristics of rheumatic carditis can result from anaphylactic hyper-

sensitivity.

Bull Johns Hopkins Hosp

1943;

: 239.

Al-Bahrani IR, Thamer MA, Al-Omeri MM, Al-Namaan YD.

Rheumatic heart disease in the young in Iraq.

Br Heart J

1966;

: 824.

Borman JB, Stern S, Shapira T, Milvidsky H, Braun K. Mitral valvoto-

my in children.

Am Heart J

1961;

: 763.

Shrivastava S, Tandon R. Severity of rheumatic mitral stenosis in chil-

dren.

Int J Cardiol

1991;

: 163–167.

Tadele H, Mekonnen W, Tefera E. Rheumatic mitral stenosis in chil-

dren: more accelerated course in sub-Saharan patients.

BMC Cardiovasc

Disord

2013;

: 95.

Horstkotte D, Niehues R, Strauer BE. Pathomorphological aspects,

aetiology and natural history of acquired mitral stenosis.

Eur Heart J

1991;

: 55–60.

Cardoso LF, Grinberg M, Rati MA,

et al.

Comparison between percu-

taneous balloon valvuloplasty and open commissurotomy for mitral

stenosis: a prospective and randomized study.

Cardiology

2002;

186–190.

10. Ben Farhat M, Ayari M, Maatouk F,

et al

. Percutaneous balloon versus

surgical closed and open mitral commissurotomy: seven-year follow-up

results of a randomized trial.

Circulation

1998;

: 245–250.

11. Reyes VP, Raju BS, Wynne J,

et al.

Percutaneous balloon valvuloplasty

compared with open surgical commissurotomy for mitral stenosis

Engl J Med

1994;

331

: 961–967.

12. Hasan-Ali H, Shams-Eddin H, Abd-Elsayed AA, Maghraby MH.

Echocardiographic assessment of mitral valve morphology after percu-

taneous transvenous mitral commissurotomy (PTMC).

Cardiovasc

Ultasound

2007;

: 48.

13. Inoue K, Owaki T, Nakamura T, Kitamura F, Miyamoto N. Clinical

application of transvenous mitral commissurotomy by a new balloon

catheter.

J Thorac Cardiovasc Surg

1984;

: 394–402.

14. Ribeiro PA, al Zaibag M, Rajendran V,

et al

. Mechanism of mitral valve

area increase by

in vitro

single and double balloon mitral valvotomy.

J Cardiol

1988;

: 264–269.

15. Reid CL, Otto CM, Davis KB, Labovitz A, Kisslo KB, McKay CR.

Influence of mitral valve morphology on mitral balloon commis-

surotomy: immediate and six-month results from the NHLBI Balloon

Valvuloplasty Registry.

Am Heart J

1992;

124

: 657–665.

16. Bonhoeffer P, Esteves C, Casal U,

et al

. Percutaneous mitral valve

dilatation with the multi-track system.

Catheter Cardiovasc Interv

1999;

: 173–183.

17. Cribier A, Eltchaninoff H, Koning R,

et al.

Percutaneous mechanical

mitral commissurotomy with a newly designed metallic valvulotome:

immediate results of the initial experience in 153 patients.

Circulation

1999;

: 793–799.

18. Lock JE, Khalilullah M, Shrivastava S, Bahl V, Keane JF. Percutaneous

catheter commissurotomy in rheumatic mitral stenosis.

N Engl J Med

1985;

313

: 1515–1518.

19. Commeau PGG, Huret B, Foucault JP, Potier JC, Commeau P, Grollier

et al

. Percutaneous mitral valvotomy in rheumatic mitral stenosis: a

new approach.

Br Heart J

1987;

: 142–147.

20. Uruchurtu Chavarin E, Sanchez A, Solis H,

et al.

Immediate results
