associated congenital heart disease should be meticulously
searched for.
When PLSVC is present, the ECG often shows an abnormal
P-wave axis and a normal or shortened PR interval. A geometric
change in the LA may be a possible mechanism for the left-axis
deviation of the P wave.
14
On chest X-ray, a crescent-shaped
shadow of the PLSVC can be seen at the aortic knob or left upper
mediastinum. After insertion of a pulmonary artery catheter into
the left subclavian or jugular vein, a control chest X-ray gives the
false appearance that the catheter has passed through the vessel.
The diagnosis can be confirmed by TTE, transoesophageal
echocardiography (TEE), venous angiography, computed tomog-
raphy (CT) or magnetic resonance imaging (MRI).
On two-dimensional B-mode TTE, the characteristic finding
is a dilated CS on parasternal long-axis view. The normal diam-
eter of the CS is smaller than 1 cm and in the case of isolated
PLSVC, severely increased flow can cause a truly giant CS.
15,16
Other causes of dilated CS are: increased RA pressure, an anom-
alous systemic or pulmonary venous connection or a fistulous
connection with the coronary arteries.
17
The next step in the echocardiographic evaluation should be
contrast application with agitated saline. In normal individuals,
agitated saline injection from the left or right antecubital vein
results in opacification of the RA. In isolated PLSVC, as in our
case, contrast given from the left or right arm opacifies the CS.
When PLSVC is associated with an unroofed CS, contrast injec-
tion from either arm results in opacification of the LA. If RSVC
accompanies the PLSVC, contrast given from the left arm first
appears in the CS, whereas contrast given from the right arm first
appears in the RA (Table 1).
On TEE, the anomalous PLSVC and absence of RSVC can
be well visualised. In mid-oesophageal views, the PLSVC can be
seen near to the left atrial appendage and left upper pulmonary
vein. In the bicaval view, the absence of RSVC can be demon-
strated. Other techniques (venous angiography, CT, MRI) direct-
ly visualise the venous anatomy and confirm the diagnosis.
In the absence of an RSVC, central venous access should be
made from the femoral vein in patients with PLSVC. During
right-sided open-heart surgical procedures, a PLSVC has to be
drained by inserting a separate cannula into it. If the PLSVC
drains into the LA and creates a large right-to-left shunt, surgical
correction should be made. Again, central venous access via the
femoral vein is a safer choice in this variation. When implanting
permanent pacemakers, the left subclavian vein is preferred, as
lead manipulation is easier. There is an acute angle between the
CS ostium and the tricuspid valve, therefore the lead should be
looped in the RA in order to enter the right ventricle.
18
Hand-
shaped stylets and active fixation leads are also helpful to over-
come technical difficulties.
19
Finally, a wide spectrum of clinicians (radiologists, sonog-
raphers, intervenists, intensivists, anaesthesiologists, cardiotho-
racic surgeons) should be aware of PLSVC and its variations in
order to avoid possible complications.
References
Danielpour PJ, Aalberg JK, El-Ramey M, Sivina M, Wodnicki H.
1.
Persistent left superior vena cava:an incidental finding during central
venous catheterisation – a case report.
Vasc Endovascular Surg
2005;
39
: 109–111.
Pálinkás A, Nagy E, Forster T, Morvai Z, Nagy E, Varga A. A case
2.
of absent right and persistent left superior vena cava.
Cardiovasc
Ultrasound
2006;
4
: 6.
Bartram U, van Praagh S, Levine JC, Hines M, Bensky AS, van Praagh
3.
R. Absent right superior vena cava in visceroatrial situs solitus.
Am J
Cardiol
1997;
80
: 175–183.
Fischer DR, Zuberbuhler JR. Anomalous systemic venous return. In:
4.
Anderson RH, Baker E, Mccartney RF, eds.
Paediatric Cardiology
. New
York: Churchill Livingstone, 2002: 851–865.
Shyamkumar NK, Brown R. Double superior vena cava with a persist-
5.
ent left superior vena cava: an incidental finding during peripherally
inserted central catheter placement.
Australas Radiol
2007;
51
(Suppl
B): 257–259.
Antretter H, Cottogni M, Oberhauser A, Lhotta K, Furtwängler W.
6.
Pacemaker implantation via a persistent left superior vena cava in
atresia of the true superior vena cava.
Dtsch Med Wochenschr
1992;
117
: 1394–1398.
Heye T, Wengenroth M, Schipp A, Johannes Dengler T, Grenacher L,
7.
Werner Kauffmann G. Persistent left superior vena cava with absent
right superior vena cava: morphological CT features and clinical impli-
cations.
Int J Cardiol
2007;
116
: e103–105.
Azocar RJ, Narang P, Talmor D, Lisbon A, Kaynar AM. Persistent left
8.
superior vena cava identified after cannulation of the right subclavian
vein.
Anesth Analg
2002;
95
: 305–307.
Recupero A, Pugliatti P, Rizzo F, Carerj S, Cavalli G, de Gregorio C,
9.
et al
. Persistent left-sided superior vena cava: integrated noninvasive
diagnosis.
Echocardiography
2007;
24
: 982–986.
Camm AJ, Dymond D, Spurrel RA. Sinus node dysfunction associ-
10.
ated with absence of right superior vena cava.
Br Heart J
1979;
41
:
504–507.
Morgan DR, Hanratty CG, Dixon LJ, Trimble M, O’Keeffe DB.
11.
Anomalies of cardiac venous drainage associated with abnormalities of
cardiac conduction system.
Europace
2002;
4
: 281–287.
Lenox CC, Hashida Y, Anderson RH, Hubbard JD. Conduction tissue
12.
anomalies in absence of the right superior caval vein.
Int J Cardiol
1985;
8
: 251–260.
Postema PG, Rammeloo LA, van Litsenburg R, Rothuis EG, Hruda J.
13.
Left superior vena cava in pediatric cardiology associated with extra-
cardiac anomalies.
Int J Cardiol
2008;
123
: 302–306.
Choi JY, Anderson RH, Macartney FJ. Absent right superior caval
14.
vein (vena cava) with normal atrial arrangement.
Br Heart J
1987;
57
:
474–478.
Arat N, Sokmen Y, Golbasi Z. Persistent left superior vena cava with
15.
absent right superior vena cava and coronary sinus dilation mimicking a
paracardiac mass.
Tex Heart Inst J
2007;
34
: 492–493.
Chan KL, Abdulla A. Images in cardiology. Giant coronary sinus and
16.
absent right superior vena cava.
Heart
2000;
83
: 704.
Neema PK, Manikandan S, Rathod RC. Absent right superior vena cava
17.
and persistent left superior vena cava:the perioperative implications.
Anesth Analg
2007;
105
: 40–42.
Hsiao HC, Kong CW, Wang JJ, Chan WL, Wang SP, Chang MS, Chiang
18.
BN. Right ventricular electrode lead implantation via a persistent
left superior vena cava. An improved technique.
Angiology
1997;
48
:
919–923.
Biffi M, Boriani G, Frabetti L, Bronzetti G, Branzi A. Left superior vena
19.
cava persistence in patients undergoing pacemaker or cardioverter-defi-
brillator implantation:a 10-year experience.
Chest
2001;
120
:139–144.
TABLE 1. ECHOCARDIOGRAPHIC DIAGNOSIS
OF PLSVCAND ITS POSSIBLEVARIATIONS
WITH CONTRASTAPPLICATION
Normal
PLSVC with-
out RSVC*
PLSVC with
RSVC
PLSVC with
unroofed CS
Contrast from
the left arm
RA CS
→
RA CS
→
RA LA
Contrast from
the right arm
RA CS
→
RA RA
LA
PLSVC: persistent left superior vena cava, RSVC: right superior vena
cava, RA: right atrium, LA: left atrium, CS: coronary sinus.
* isolated PLSVC.
